Description
Product details
Type of sensor : Insertion Paddle Wheel Service : Any clear liquids Max. % of Solids : 1% of fluid volume, non-abrasive, non-magnetic,<100 micron in dia.& length Mounted : Field Pressure drop : Less than 0.1 bar Accuracy : +/- 1% of Full Scale if velocity is more than 0.5 m/s Repeatability : +/- 0.5% Enclosure : IP 65 or, Flameproof Fitting material : ABS, SS304 or, SS316 Fitting Type : T type Welded Flanged ends Sensor Cable Length : 0.5 meters signal transmission cable Output Cable Length : Two core shielded wire - One Meter Paddle : PVDF Indicator Housing : Polycarbonate O-rings : Viton Sensor Rod : PP or, SS 316 Display : 8 X 2 alpha-numeric (Backlit) 7 digits for Total & 4 digits for rate Unit for indication : LPM, LPH, M3/Hr, USGPM Out Put : 4 to 20 mA Supply : 230 V AC +/- 15%, 50 Hz T Fitting : It is compulsory with PP or, SS Flow Sensors (Selection from TYPE OF T-FITTINGS) Line Size Selection (Water) : Min. & Max. Flow Rates NB MINIMUM M3/HR MAXIMUM M3/HR 15 0.2 2.1 25 0.8 8 40 1.9 19 50 3.5 35 65 5.8 58 80 7.5 75 100 14 140 125: 5' 22 220 150: 6' 32 320 175: 7' 45 450 200: 8' 56 560 225: 9' 71 710 250: 10' 88 880 275: 11' 106 1060 300:12' 126 1260 325:13' 148 1480 350:14' 172 1720 375:15' 197 1970 400:16' 224 2240
