We have various type of Pressure Transmitters, which would be selected on the basis of application, details of medium and its max. pressure and Temperature. The basic use of Pressure Transmitter is to Sense the pressure in the process and to give its proportionate output to the device which will either indicate the values in Pressure Terms or it will give some Controlled Output. We have a very common Miniature Pressure Transmitters, Miniature Transmitters with integral Digital Display, Miniature Pressure Transmitter with Integral Bar Graph Display, Pressure Transmitters with integral LCD display, Smart Pressure Transmitters etc. All these transmitters can be provided as Flush Diaphragm type Pressure Transmitter, Pressure Transmitter with Triclover connection, Pressure Transmitter with Remote Diaphragm Seal, Pressure Transmitter with Flange connection, Pressure Transmitter in Flameproof version etc.

We have Vacuum Sensors and Switches for Indication & Control applications. Vacuum Switches & Compound Range Switches are normally used in Vacuum Pumps or, Vacuum based systems where you have to ensure availability of Vacuum within Low & High set limits. So using Vacuum Switches you can control your process in On-Off mode. Vacuum Transmitters are used to know actual availability of Vacuum in the process and the same can be used to read or, control in proportionate or, On-Off mode. Flameproof Vacuum Switch is designed as per IS2148 for Gas Gr. IIC Flameproof - CE Certification and approved by a leading European Lab – “BASEEFA” for ATEX & ICEEX certificates Adjustable Range : 760 to 100 mm Hg Vacuum Diaphragm : Teflon or, Neoprene Pressure Housing MOC : Aluminium, Brass or, SS 316

Type of sensor : Insertion Paddle Wheel Service : Any clear liquids Max. % of Solids : 1% of fluid volume, non-abrasive, non-magnetic,<100 micron in dia.& length Mounted : Field Pressure drop : Less than 0.1 bar Accuracy : +/- 1% of Full Scale if velocity is more than 0.5 m/s Repeatability : +/- 0.5% Enclosure : IP 65 or, Flameproof Fitting material : ABS, SS304 or, SS316 Fitting Type : T type Welded Flanged ends Sensor Cable Length : 0.5 meters signal transmission cable Output Cable Length : Two core shielded wire - One Meter Paddle : PVDF Indicator Housing : Polycarbonate O-rings : Viton Sensor Rod : PP or, SS 316 Display : 8 X 2 alpha-numeric (Backlit) 7 digits for Total & 4 digits for rate Unit for indication : LPM, LPH, M3/Hr, USGPM Out Put : 4 to 20 mA Supply : 230 V AC +/- 15%, 50 Hz T Fitting : It is compulsory with PP or, SS Flow Sensors (Selection from TYPE OF T-FITTINGS) Line Size Selection (Water) : Min. & Max. Flow Rates NB MINIMUM M3/HR MAXIMUM M3/HR 15 0.2 2.1 25 0.8 8 40 1.9 19 50 3.5 35 65 5.8 58 80 7.5 75 100 14 140 125: 5' 22 220 150: 6' 32 320 175: 7' 45 450 200: 8' 56 560 225: 9' 71 710 250: 10' 88 880 275: 11' 106 1060 300:12' 126 1260 325:13' 148 1480 350:14' 172 1720 375:15' 197 1970 400:16' 224 2240

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We have Differential Pressure Gauge with Switches, which are useful in industrial applications like Automatic cleaning systems for Heat Exchangers and various type of expensive Filters. We have few options in the same : Differential Pressure Gauge with one Switch, Differential Pressure Gauge with Duel Switches or, Differential Pressure Gauge with Flameproof Switching contacts. The type of Differential Pressure Gauge with Switches are : Piston type DP Gauge with Switch - These are offered when medium in both the ports are same and slight migration is acceptable. Diaphragm type DP Gauge with Switch - These are recommended where migration of mediums in two ports in not acceptable. & Digital DP Gauge with Switch (Digital DP Indicator with Swicthing contacts) - For high accuracy applications these are recommended..

Adjustable Range : -1.0 to +1.0 bar Enclosure : IP 66 Contact parts : SS 316 & Teflon Compound Pressure range means range coverage from Vacuum up to +ve Pressure. NK Instruments Pvt. Ltd. has Compound range Pressure Switches, which are suggested when the set point is in Vacuum but normally there is +ve pressure in that process Or, vice versa. These switches are available in Weatherproof and Flameproof versions also, as shown below:
