We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We have Paddle type Flow Switches, which can be provided for various mediums like Clear Liquids or, Liquid containing suspended particles, various type of Oils, Air and Gases. These Flow Switches are available in Weatherproof, Flameproof to Group IIA, IIB enclosure and Flameproof to group IIC enclosure. We have Paddle operated Flow Switches with Bellow Seals or, working with Magnetic Coupling principle. WFSPT -General purpose WP-FSPT -Weatherproof Flow Switches EP-FSPT -Explosion proof Flow Switches to group IIA/IIB GFP-FSPT -Flameproof Flow Switches to group IIC WPFS -10R & WPFS-15R -Low Flow Paddle type Flow Switches MFSPT -Magnetic Repulsion type Flow Switches AFSPT -Air Flow Switches AFSPT -Mini Air Flow Switches Service : Liquids, Slurries, Air and Gases Mounting : On Vertical or Horizontal Mounted pipe line Line Size : For any pipe line size above 1/2' Flow set point : Prefixed or, Field Adjustable Paddle Material : SS Sealing type : With SS Bellow or, without Bellow Switch type : SPDT Micro switch (5A or, 15 A) Repeatability : Better than +/- 1% Accuracy : +/-2.0 % Max. Working Pressure : 10 bar Max. Working Temperature : 100 degree C

We have Paddle type Flow Switches, which can be provided for various mediums like Clear Liquids or, Liquid containing suspended particles, various type of Oils, Air and Gases. These Flow Switches are available in Weatherproof, Flameproof to Group IIA, IIB enclosure and Flameproof to group IIC enclosure. We have Paddle operated Flow Switches with Bellow Seals or, working with Magnetic Coupling principle. WFSPT -General purpose WP-FSPT -Weatherproof Flow Switches EP-FSPT -Explosion proof Flow Switches to group IIA/IIB GFP-FSPT -Flameproof Flow Switches to group IIC WPFS -10R & WPFS-15R -Low Flow Paddle type Flow Switches MFSPT -Magnetic Repulsion type Flow Switches AFSPT -Air Flow Switches AFSPT -Mini Air Flow Switches Service : Liquids, Slurries, Air and Gases Mounting : On Vertical or Horizontal Mounted pipe line Line Size : For any pipe line size above 1/2' Flow set point : Prefixed or, Field Adjustable Paddle Material : SS Sealing type : With SS Bellow or, without Bellow Switch type : SPDT Micro switch (5A or, 15 A) Repeatability : Better than +/- 1% Accuracy : +/-2.0 % Max. Working Pressure : 10 bar Max. Working Temperature : 100 degree C

Enclosure : Sealed Ingress Protection to IP 67 to BS EN60947-1 and Flameproof to group IIA/IIB CCOE Certified Material : Die-Cast Zinc alloy, Mazak III Finish : Chromate Passivation with Polyester Point (Grey) Set level range : 0.5 to 9g Peak acceleration Contact Rating with Silver Contacts : 5 A 240 VAC (non-inductive) SPCO 3 A 30 VDC (non-inductive) up to 1 million operations 4 A 240 VAC per contact for D Pole Versions In case of Gold Contacts : 0.5 A 30 VDC max for 1.S. Currents Contact Arrangements : SPCO or, DPCO Temperature range : -55 to +85°C Electrical Reset : Manual

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

We provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

e provide Process Indicators and Process Indicating Controllers as per the clients demand & the process needs. Input can be 4 to 20 mA, 0 to 10 V or, pulses, resistance etc. Output can be Potential Free Contacts (Single / Two or, Four nos.) or, Re-transmitter etc. Display will be LED 7 segment or, LCD Power Supply can be 230 V AC, 110 V AC, 24 V DC or, 12 V DC Mounting types can be Panel mounted, Wall Mounted or, Field mounted Enclosure types can be IP 40, IP 54, IP 65 or, Flameproof

Compact type Pressure Transmitters are also known as Blind Pressure Transmitter, Pencil type Pressure Transmitters or, Miniature Pressure Transmitters. Compact Pressure Transmitters are available in various ranges, accuracies, and the type of enclosures. Indication : Without Ranges : Various ranges from 0 to 100 mbar up to 0 to 700 bar Output options : 4 to 20 mA, 0 to 10 Vdc, 1 to 5 Vdc or, 0.5 to 4.5 V dc under 5 V dc Accuracy : +/- 0.1%, 0.2%, 0.25%, 0.4%, 0.5% of FS Enclosure type : IP 65, IP 67, IP 68, ATEX certified. Max. pressure : 1.5 Times of Working Pressure. Zero and Span Adjustment : Without (It is possible only in specific ranges and types) Process connection options : 1/4' BSP (M), 1/2' BSP (M), Flush Diaphragm, Tri clamp. Operating Temperature : 0 to 100 (Standard) by using suitable accessories we can offer the same Pressure Transmitter for temperature up to 250° C
